Wheel man

The wheel is done but not without some drama and disappointment. The initial plan was to shape it, prime it and finish it with the Seymour custom rattle can lacquer from NPD. From there I’d do a spray out and see if that coating could be cleared. After shaping and high build primer a couple coats of Transtar epoxy primer is laid down.

Just a bit short of the 1:1 mix ratio with the activator. It still mixed and applied well.
Primed and ready for topcoat.
Topped with the rattle can lacquer.

The secret of getting as good a finish as you can is all about the layers. They need to bond together to produce a strong, smooth finish. Many if not most custom painters use coatings and chemicals from the same product family or at least known combinations. For example the last full paint job i did I used PPG Deltron as the color with Tamco reducers and Euro style clear. The Tamco materials are made from BASF resins and are high quality. They’re basically PPG clones at a much more reasonable price.

Using a non catalyzed color coat over higher end primers could be problematic depending on the top coat. Quality auto finish products have tech sheets that detail how to apply, when it should be applied and other info like sanding grit and surface prep. Unfortunately the NPD clone lacquer (or any of the NPD mixed paints) has no tech sheet. Using the paint to top the epoxy primer was a disaster. It was coating failure city.

About 30 mins after shooting the coating started to shrink. The patterns were inconsistent which makes me think the coating wasn’t compatible with the substrate.
Initially it laid out great. After 30-40 mins it started failing.

That is a gigantic bummer. It’s going to require stripping all the color coat from the part. Once a coating starts to fail it’s best to take it all off. If it’s failing now leaving it as part of the substrate is asking for trouble. Out of epoxy primer I hit the local auto body finishing joint and opted for a can of Transtar 1k primer. It was a bit more rough than I’d like compared to the epoxy. The epoxy is about $80/qt with activator. The 1k is about $15 a can. And like the other Transtar products has a tech sheet so you know if it’s compatible with your application.

I stripped a great deal of the failed coating with Kleen Strip aircraft stripper. I normally use a heavy concentrate of methylene chloride (powercoat stripper) but I was out and the local supplier was out as well. For the rest I used a DA at 120 grit to 220 grit to 320 grit. It took a lot of the smoothness of the shaping off the part. It took about an hour to get the part to the point where I could apply the primer. The primer went on well though not quite as smooth as I’d like. The epoxy is self leveling which is one of the reasons it cures smooth.

I had to change the strategy on the color coat. The Light Ivy Gold I used originally (and on the interior trim) wasn’t exactly the right color for the wheel. I had some difficulty finding a color code for Light Ivy Gold. My local PPG and Axalta jobber went from being a great locally owned, family run high end auto paint jobber to getting bought out by a large chain when the family decided to get out. If you get the counter boss, who likes to insert himself in each transaction, it’s more like an argument or trying to convince him what he thinks I want to do isn’t what he thinks I’m saying.

For example if I say “I’m looking for 1967 Ford paint code I” (Lime Gold Poly). I get told that’s not a valid factory code. Not now it’s not but I need the one from 1967. You know, about 20 years before you were born. PPG 2054. Or when asked for the proper color name I say “Lime Gold Poly”. “Poly? Poly what?” That’s what they called metallic back in the olden days. “OK, so you want Metallic Lime Gold?” Never mind that that nice lady that was helping me before he horned in on the deal had the code and printed the mixing tags. He was “going to check, just to be sure”.

It was one of the longest 30 mins of my life. I bought the Omni MBC budget line from PPG. A quart of Omni is $50, a quart of PPG Deltron (the good stuff) is $150. My guy back east can get me a gallon of Deltron for $225 shipped ($175 plus $50 shipping). From the local jobber the Deltron is around $500/gal. There was some other back and forth about which colors are available in Deltron that aren’t available in Omni. On the plus side I did get to see a spray out of Ditzler Hot Rod Black to compare to the Krylon rattle can that is used in the engine bay. I’m going to use catalyzed auto paint for the rest of the project (even though the rattle can NPD worked great on the dash and interior). The HRB isn’t an exact match but it plenty close for my driver project.

Pleased with the Omni base coat so far. It mixes and lays down well. Not as silky as Deltron but much more affordable and a good color consistency. I used Tamco medium reducer.

Some focus and shadow issues with the pic. A spray out with the Transtar 1k white primer, Omni MBC with three coats of Tamco Glamour Clear 2100. (since discontinued, it’s what’s left over from about a year and a half ago, current product is HC2104. It’s not even close to matching the One Day Paint sun faded single stage from the last collision repair. Or I should say the collision shop paint isn’t close to what Lime Gold Poly should be. The pic doesn’t do it justice.
Old clear, probably past the shelf life but good enough for the steering wheel and a spray out. Self leveling, goes on easy for a novice and is quite affordable. It’s basically a PPG 2021 though Tammy (the Tam of Tamco) compares it more to Glasurit.
Finished product. It’s going to need some color sanding to smooth some of the inside rim. I got in a hurry and should have re-glazed and shaped the inside of the rim but didn’t.

All in all it could have gone better. Having to top coat it again cost about four hours. It’s better than it was by far but there are some details I wish I had done better. We’ve also been working on the seats. What was left of the foam was shot and the mice got the batting in the rear seat. The seats are a lot tougher to finish than they look.

Steering wheel restoration

The steering wheel was baked from years in the sun. Rather than buying a reproduction I decided to refurbish the one I have. The repros are about $200. I have most of the material for this, the only thing I needed was panel bond so I’ve got about $35 out of pocket but it’s far more material than I need for this job. The cost of the materials used is well under $50 total including the finish paint. If you didn’t have the materials I would guesstimate $100-120 to buy it or just under $100 for a kit from Eastwood or the like. My goal is to use as many of the original parts as I can even if the cost to restore is at or near the replacement cost.

From years in the sun.
Continue reading “Steering wheel restoration”

Radio, radio

Not as much progress as I would like. Between some middle aged man maladies and a change of the schedule when the day gig goes dark for a couple of weeks the time is eaten away. I’ve hit some milestones, seats are well under way, the radio upgrade is complete and the steering wheel restoration is progressing.

Original AM radio.
Continue reading “Radio, radio”

Ladies and gentlemen the doors

With the carpet and seats underway the rest of the interior painting needs to be completed. The interior was painted during that mid 90s refresh with the other bits. I did find the paint used in a box with various parts, new and used, that were in the car. It wasn’t exactly Ivy Gold. When I first got the Ivy Gold for this after I did the spray out I noticed it was a fair bit off. The old can of Krylon in the box explains that. I don’t even know if they had period/material correct interior paint for the Ponys back then.

I like the paint. It’s Seymour rattle can lacquer mixed by NPD. While the color is a great match I’m not wild about the application. It’s prone to sputter and clogging unless you do some specific things. It’s a heavy bodied metallic and real lacquer. That’s awesome for the color but makes application a bit more difficult than rattle can enamel.

This is the back masking from painting various parts. Notice the amount of silver metallic overspray. It’s something that makes the application of this particular coating different from other coatings.
Continue reading “Ladies and gentlemen the doors”

Cranking on the interior

With the holidays over it’s time to start updating on the progress. It’s still been a slog. One thing leads to another leads to another. I am at the point where I’m able to start final assembly on the interior. But first here’s where we’ve been over the last month.

We’re using the carpet that came out of the car. It was installed in the mid 90s when the last refresh happened. It was dirty, the backing was trashed but otherwise it’s not in bad shape. With some jute backing from Mac’s, Tuff Stuff, a Spot Bot with Bissell heavy duty carpet shampoo and a bunch of elbow grease she whipped the carpet back into shape. Here’s the rear section, the front was the same thing.
